基于分布式声波传感的潮汐作用下海浪冲击规律研究

程琛; 唐振宇; 谭道远; 王静; 于洋; 朱鸿鹄; 苏晶文

doi:10.19509/j.cnki.dzkq.tb20250015

基于分布式声波传感的潮汐作用下海浪冲击规律研究

doi: 10.19509/j.cnki.dzkq.tb20250015

程琛^{1, 2,},
唐振宇¹,
谭道远^{1, 2, ,},
王静¹,
于洋³,
朱鸿鹄¹,
苏晶文⁴

1.
南京大学地球科学与工程学院，南京 210023
2.
自然资源部地裂缝地质灾害重点实验室，南京 210049
3.
浙江大学海洋学院，浙江舟山 316021
4.
中国地质调查局南京地质调查中心，南京 210016

基金项目: 自然资源部地裂缝地质灾害重点实验室开放基金项目（JSDDYHJD2024007）；江苏省基础研究计划自然科学基金青年基金项目（BK20241211）；国家自然科学基金青年项目（42407250）

详细信息

作者简介:
程琛：E-mail：chen_cheng@smail.nju.edu.cn

通讯作者:
E-mail：dytan@nju.edu.cn

计量
- 文章访问数: 362
- PDF下载量: 47
- 被引次数: 0
出版历程
- 收稿日期: 2025-01-09
- 录用日期: 2025-06-09
- 修回日期: 2025-06-06
- 网络出版日期: 2025-06-10

Study on wave impact patterns under tidal influence based on distributed acoustic sensing

CHENG Chen^{1, 2
,},
TANG Zhenyu¹,
TAN Daoyuan^{1, 2
, ,},
WANG Jing¹,
YU Yang³,
ZHU Honghu¹,
SU Jingwen⁴

1.
School of Earth Sciences and Engineering, Nanjing University, Nanjing 210023, China
2.
Key Laboratory of Earth Fissures Geological Disaster, Ministry of Natural Resources, Nanjing 210049, China
3.
Ocean College, Zhenjiang University, Zhoushan Zhejiang 316021, China
4.
Nanjing Center, China Geology Survey, Nanjing 210016, China

More Information

Author Bio:
E-mail：chen_cheng@smail.nju.edu.cn

Corresponding author: E-mail：dytan@nju.edu.cn

摘要

摘要:
本研究旨在定量分析潮汐作用下的海浪冲击强度及其与潮汐特征和地形之间的关系，为海岸侵蚀机制研究和沿海防护工程设计提供科学依据。利用分布式声波传感（DAS）技术对浙江省舟山市摘箬山岛北部海岸的海浪冲击过程进行了为期21 d的有效监测，结合潮汐数据和功率谱密度（PSD）分析了潮汐作用下的海浪冲击动态规律。结果表明，潮位高度、潮汐强度和地形特征共同影响海浪冲击的强度与分布。在观测期内，海浪冲击强度与潮汐强度变化呈现出一致性：大潮期间海浪的冲击作用最为显著，尤其在满潮点的潮位高度超过特定阈值时，冲击作用明显增强；中潮期间海浪的冲击过程表现出多阶段、多峰值特征；而小潮期间冲击作用相对较弱，主要集中在退潮阶段。此外，地形特征显著调控了冲击分布：东侧海岸因潮汐作用时间较长，冲击持续时间更久，而凹陷区域因潮流引发的波浪相互抵消，冲击较弱。本研究验证了DAS技术在监测潮汐作用下海浪冲击规律中的有效性，揭示了潮汐特征与地形因素对海浪冲击的协同调控机制，为深入理解海浪冲击动力学过程和沿海防护策略优化提供了重要的数据支持。
- 潮汐 /
- 海浪冲击 /
- 分布式声波传感（DAS） /
- 功率谱密度（PSD） /
- 地质灾害监测 /
- 海洋防护
Abstract:
Objective
Wave impact under tidal influence is a critical factor affecting coastal erosion. However, studies focusing on the independent effects of tidal characteristics on wave impact remain relatively limited. This study aims to quantitatively analyze wave impact intensity under tidal influence and its relationship with tidal characteristics and topography, providing a scientific basis for research on coastal erosion mechanisms and the design of coastal protection engineering.
Methods
Using distributed acoustic sensing (DAS) technology, the wave impact processes along the northern coast of Zhairuoshan Island, Zhoushan, Zhejiang Province were effectively monitored for 21 days. A 160-meter fiber-optic sensing cable was deployed for DAS measurements, and the dynamic patterns of wave impact under tidal influence were analyzed by integrating power spectral density (PSD) energy and tidal data.
Results
The results showed that tidal height, tidal intensity, and topographic features collectively affected the intensity and distribution of wave impact. During the observation period, wave impact intensity showed consistency with tidal intensity variations. Wave impact was most significant during spring tides, particularly when high-tide levels exceeded a specific threshold, and the impact was significantly enhanced. During intermediate tides, wave impact exhibited multi-stage and multi-peak characteristics. In contrast, wave impact during neap tides was relatively weak and mainly concentrated during the ebb tide phase. In addition, topographic features significantly regulated the spatial distribution of wave impact. The eastern coast experienced prolonged impact due to extended tidal duration, while concave areas exhibited weaker impact due to wave cancellation induced by tidal currents.
Conclusion
This study verifies the effectiveness of DAS technology in monitoring wave impact patterns under tidal influence, reveals the synergistic regulation mechanisms of tidal characteristics and topographic factors on wave impact, and provides important data support for a deeper understanding of wave impact dynamics and optimization of coastal protection strategies.
- tides /
- wave impact /
- distributed acoustic sensing (DAS) /
- power spectral density (PSD) /
- monitoring of geological hazards /
- coastal protection

HTML全文

图 1 研究区域及现场光缆布设示意图

a. 研究区域位置及地形；b. 光缆布设及设备位置；c. 现场监测图。DAS. 分布式声波传感

Figure 1. Study area and on-site optical cable deployment

下载: 全尺寸图片幻灯片

图 2 DAS技术传感原理图

$ {V}_{0} $为入射光的中心频率；$ {V}_{\text{B}} $为布里渊频移量；$ {V}_{\text{R}} $为拉曼频移量

Figure 2. DAS sensing principle

下载: 全尺寸图片幻灯片

图 3 监测期间潮位(a)与能量(b)对应图

Figure 3. Relationship between tidal level (a) and energy (b) during monitoring period

下载: 全尺寸图片幻灯片

图 4 2024年5月2日—2024年5月4日期间PSD能量与潮位对应关系

Figure 4. Relationship between PSD energy and tidal level (May 2, 2024-May 4, 2024)

下载: 全尺寸图片幻灯片

图 5 大潮（a1～d1）、中潮（a2～d2）和小潮（a3～d3）期间PSD能量与潮位的对应关系图

Figure 5. Relationship between PSD energy and tidal level during spring tides (a1-d1), intermediate tides (a2-d2) and neap tides (a3-d3)

下载: 全尺寸图片幻灯片

图 6 不同潮汐强度期间各通道总能量对比

Figure 6. Comparison of total energy across various channels under different tidal intensities

下载: 全尺寸图片幻灯片

图 7 监测日期内的最大潮差和总能量之间的相关性

R. 最大潮差与总能量之间的相关系数

Figure 7. Correlation between maximum tidal range and total energy during monitoring period

下载: 全尺寸图片幻灯片

图 8 监测期间各通道的能量和与地形的对应关系

a.各通道对应的海岸位置示意图；b～d.各周的PSD能量和；e.监测期间各通道总能量和

Figure 8. Relationship between cumulative energy of various channels and topography during monitoring period

下载: 全尺寸图片幻灯片

表 1 光缆的基本技术指标

Table 1. Basic technical specifications of the optical cable

光纤类型	纤芯数量/根	截面直径/mm	光栅间距/m	护套材料
单模	1	2	2	聚氨酯

下载: 导出CSV

表 2 DAS解调仪的设备参数

Table 2. Parameters of DAS demodulator

参数名称	数值	参数名称	数值
通道数/个	1	灵敏度	＜0.05 nε@5～10 Hz
探测距离/km	0～20	平均故障间隔时间/h	>750
响应频段/kHz	0～50	授时精度/μs	≤5
空间采样间隔/cm	≥10
定位精度/m	2, 5, 10

下载: 导出CSV

表 3 DAS解调仪的基本技术指标

Table 3. Basic technical specifications of DAS demodulator

采样频率/Hz	道间距/m	标距长度/m	监测分量	记录模式	授时模式
500	2	2	单分量	连续记录	GPS授时

下载: 导出CSV

参考文献(41)

[1]	李平, 丰爱平, 孙惠凤, 等. 海岸侵蚀灾害调查和评价研究进展与展望[J]. 自然灾害学报, 2021, 30(4): 55-63. doi: 10.13577/j.jnd.2021.0406 LI P, FENG A P, SUN H F, et al. Research progress and prospect of coastal erosion investigation and evaluation[J]. Journal of Natural Disasters, 2021, 30(4): 55-63. (in Chinese with English abstract doi: 10.13577/j.jnd.2021.0406
[2]	陈君, 林祥. 江苏海岸侵蚀及其防护工程研究进展[J]. 水利水电科技进展, 2024, 44(5): 1-6. doi: 10.3880/j.issn.1006-7647.2024.05.001 CHEN J, LIN X. Research progress on coastal erosion and protection engineering in Jiangsu Province[J]. Advances in Science and Technology of Water Resources, 2024, 44(5): 1-6. (in Chinese with English abstract doi: 10.3880/j.issn.1006-7647.2024.05.001
[3]	宫立新. 山东半岛东部海滩侵蚀现状与保护研究[D]. 山东青岛: 中国海洋大学, 2014. GONG L X. Erosion situation and protection of beach in eastern part of Shandong Peninsula[D]. Qingdao Shandong: Ocean University of China, 2014. (in Chinese with English abstract
[4]	于德海, 彭建兵, 李滨. 海岸带侵蚀灾害研究进展及思考[J]. 工程地质学报, 2010, 18(6): 867-872. doi: 10.3969/j.issn.1004-9665.2010.06.009 YU D H, PENG J B, LI B. Review and reflection on coastal erosion disaster[J]. Journal of Engineering Geology, 2010, 18(6): 867-872. (in Chinese with English abstract doi: 10.3969/j.issn.1004-9665.2010.06.009
[5]	孙杰, 詹文欢, 姚衍桃, 等. 广东省海岸侵蚀现状及影响因素分析[J]. 海洋学报(中文版), 2015, 37(7): 142-152. doi: 10.3969/j.issn.0253-4193.2015.07.014 SUN J, ZHAN W H, YAO Y T, et al. Current situation and influence factors of coastal erosion in Guangdong[J]. Haiyang Xuebao, 2015, 37(7): 142-152. (in Chinese with English abstract doi: 10.3969/j.issn.0253-4193.2015.07.014
[6]	王奎博, 张丽, 王瑞琪, 等. 海南岛海岸侵蚀脆弱性评价[J]. 遥感技术与应用, 2022, 37(5): 1149-1158. WANG K B, ZHANG L, WANG R Q, et al. Evaluation of coastal erosion vulnerability in Hainan Island[J]. Remote Sensing Technology and Application, 2022, 37(5): 1149-1158. (in Chinese with English abstract
[7]	WOLF J. Coastal flooding: Impacts of coupled wave-surge-tide models[J]. Natural Hazards, 2009, 49(2): 241-260.
[8]	IDIER D, BERTIN X, THOMPSON P, et al. Interactions between mean sea level, tide, surge, waves and flooding: Mechanisms and contributions to sea level variations at the coast[J]. Surveys in Geophysics, 2019, 40(6): 1603-1630.
[9]	KANG K, KIM S. Wave-tide interactions during a strong storm event in Kyunggi Bay, Korea[J]. Ocean Engineering, 2015, 108: 10-20.
[10]	HO A, MERRIFIELD S, PIZZO N. Wave-tide interaction for a strongly modulated wave field[J]. Journal of Physical Oceanography, 2023, 53(3): 915-927. doi: 10.1175/jpo-d-22-0166.1
[11]	LEWIS M J, PALMER T, HASHEMI R, et al. Wave-tide interaction modulates nearshore wave height[J]. Ocean Dynamics, 2019, 69(3): 367-384. doi: 10.1007/s10236-018-01245-z
[12]	PLESKACHEVSKY A, EPPEL D P, KAPITZA H. Interaction of waves, currents and tides, and wave-energy impact on the beach area of Sylt Island[J]. Ocean Dynamics, 2009, 59(3): 451-461. doi: 10.1007/s10236-008-0174-1
[13]	HOFLAND B, KAMINSKI M, WOLTERS G. Large scale wave impacts on a vertical wall[J]. Coastal Engineering Proceedings, 2011(32): 15. doi: 10.9753/icce.v32.structures.15
[14]	CUOMO G, ALLSOP W, TAKAHASHI S. Scaling wave impact pressures on vertical walls[J]. Coastal Engineering, 2010, 57(6): 604-609. doi: 10.1016/j.coastaleng.2010.01.004
[15]	GUZAR T, BOWEN A J. Resonant interactions for waves breaking on a beach[C]//Anon. Coastal Engineering 1976. Honolulu: American Society of Civil Engineers, 1977: 560-579.
[16]	VELDMAN A E P, LUPPES R, BUNNIK T, et al. Extreme wave impact on offshore platforms and coastal constructions[C]//Anon. Volume 7: CFD and VIV; Offshore Geotechnics. Rotterdam: ASMEDC, 2011: 365-376.
[17]	LIM M, ROSSER N J, PETLEY D N, et al. Quantifying the controls and influence of tide and wave impacts on coastal rock cliff erosion[J]. Journal of Coastal Research, 2011, 27(1): 46-56. doi: 10.2112/jcoastres-d-09-00061.1
[18]	MOON I J. Impact of a coupled ocean wave-tide-circulation system on coastal modeling[J]. Ocean Modelling, 2005, 8(3): 203-236. doi: 10.1016/j.ocemod.2004.02.001
[19]	刘威, 朱鸿鹄, 王涛, 等. 基于分布式声波传感的大地探测技术研究进展[J]. 地质科技通报, 2023, 42(1): 29-41. doi: 10.19509/j.cnki.dzkq.2022.0228 LIU W, ZHU H H, WANG T, et al. Research progress of earth exploration technologies based on distributed acoustic sensing[J]. Bulletin of Geological Science and Technology, 2023, 42(1): 29-41. (in Chinese with English abstract doi: 10.19509/j.cnki.dzkq.2022.0228
[20]	曹凯, 吴建宁, 卢渊, 等. 煤矿采空区覆岩破裂分布式声波传感监测[J]. 地质科技通报, 2024, 43(6): 125-135. doi: 10.19509/j.cnki.dzkq.tb20240215 CAO K, WU J N, LU Y, et al. Distributed acoustic sensing monitoring of overburden fractures in coal mine goaf[J]. Bulletin of Geological Science and Technology, 2024, 43(6): 125-135. (in Chinese with English abstract doi: 10.19509/j.cnki.dzkq.tb20240215
[21]	刘威, 朱鸿鹄, 张汉羽, 等. 基于分布式声波传感阵列的地震动事件定位可行性研究[J]. 中南大学学报(自然科学版), 2023, 54(5): 1804-1813. doi: 10.11817/j.issn.1672-7207.2023.05.015 LIU W, ZHU H H, ZHANG H Y, et al. Feasibility study of seismic events positioning based on distributed acoustic sensing array[J]. Journal of Central South University (Science and Technology), 2023, 54(5): 1804-1813. (in Chinese with English abstract doi: 10.11817/j.issn.1672-7207.2023.05.015
[22]	CHEN Z, ZHANG C C, SHI B, et al. Detecting gas pipeline leaks in sandy soil with fiber-optic distributed acoustic sensing[J]. Tunnelling and Underground Space Technology, 2023, 141: 105367. doi: 10.1016/j.tust.2023.105367
[23]	WEI J Y, GONG W D, XING J H, et al. Distributed acoustic sensing technology in marine geosciences[J]. Intelligent Marine Technology and Systems, 2024, 2: 26. doi: 10.1007/s44295-024-00039-y
[24]	SLADEN A, RIVET D, AMPUERO J P, et al. Distributed sensing of earthquakes and ocean-solid Earth interactions on seafloor telecom cables[J]. Nature Communications, 2019, 10: 5777. doi: 10.1038/s41467-019-13793-z
[25]	WILLIAMS E F, FERNÁNDEZ-RUIZ M R, MAGALHAES R, et al. Distributed sensing of microseisms and teleseisms with submarine dark fibers[J]. Nature Communications, 2019, 10: 5778. doi: 10.1038/s41467-019-13262-7
[26]	LINDSEY N J, DAWE T C, AJO-FRANKLIN J B. Illuminating seafloor faults and ocean dynamics with dark fiber distributed acoustic sensing[J]. Science, 2019, 366: 1103-1107. doi: 10.1126/science.aay5881
[27]	SPICA Z J, NISHIDA K, AKUHARA T, et al. Marine sediment characterized by ocean-bottom fiber-optic seismology[J]. Geophysical Research Letters, 2020, 47(16): e2020GL088360.
[28]	HU D J J, ZHANG H L, DONG H, et al. Submarine cable-based distributed acoustic sensing for tide monitoring[J]. IEEE Sensors Journal, 2024, 24(21): 34410-34416. doi: 10.1109/JSEN.2024.3429158
[29]	石景元, 张功瑾. 舟山海域潮汐特征及调和分析精度研究[J]. 海洋技术学报, 2022, 41(3): 83-89. doi: 10.3969/j.issn.1003-2029.2022.03.010 SHI J Y, ZHANG G J. Research on tidal characteristics and harmonic analysis accuracy in the Zhoushan Sea area[J]. Journal of Ocean Technology, 2022, 41(3): 83-89. (in Chinese with English abstract doi: 10.3969/j.issn.1003-2029.2022.03.010
[30]	侯伟芬, 潘玉英, 冯心妍. 舟山岙山岛西南侧海域潮汐潮流特征分析[J]. 浙江海洋大学学报(自然科学版), 2022, 41(6): 536-541. doi: 10.3969/j.issn.1008-830X.2022.06.009 HOU W F, PAN Y Y, FENG X Y. Analysis of the tide and tidal current characteristics on the southwest side of Zhoushan Aoshan Island[J]. Journal of Zhejiang Ocean University (Natural Science), 2022, 41(6): 536-541. (in Chinese with English abstract doi: 10.3969/j.issn.1008-830X.2022.06.009
[31]	李卫丁, 王燕妮. 舟山本岛南部附近海域潮汐潮流特征分析[J]. 海洋开发与管理, 2019, 36(3): 64-68. LI W D, WANG Y N. The characteristics of tidal currents near the southern coast of Zhoushan Island[J]. Ocean Development and Management, 2019, 36(3): 64-68. (in Chinese with English abstract
[32]	HE Z Y, LIU Q W. Optical fiber distributed acoustic sensors: A review[J]. Journal of Lightwave Technology, 2021, 39(12): 3671-3686. doi: 10.1109/JLT.2021.3059771
[33]	OPPENHEIM A V. Discrete-time signal processing[M]. Chennai: Pearson Education India, 1999.
[34]	刘伯胜. 水声学原理[M]. 3版. 北京: 科学出版社, 2019. LIU B S. Principles of underwater acoustics[M]. 3rd ed. Beijing: Science Press, 2019. (in Chinese)
[35]	WELCH P. The use of fast Fourier transform for the estimation of power spectra: A method based on time averaging over short, modified periodograms[J]. IEEE Transactions on Audio and Electroacoustics, 1967, 15(2): 70-73. doi: 10.1109/TAU.1967.1161901
[36]	SOLOMON JR O M. PSD computations using Welch's method[J]. NASA STI/Recon Technical Report N, 1991, 92: 23584.
[37]	STEWART R H. Introduction to physical oceanography[M]. [S. l. ]: Robert H. Stewart, 2008.
[38]	陈倩, 黄大吉, 章本照, 等. 浙江近海潮汐的特征[J]. 东海海洋, 2003, 21(2): 1-12. doi: 10.3969/j.issn.1001-909X.2003.02.001 CHEN Q, HUANG D J, ZHANG B Z, et al. The research of the tidal features in the coastal zone of Zhejiang Province[J]. Donghai Marine Science, 2003, 21(2): 1-12. (in Chinese with English abstract doi: 10.3969/j.issn.1001-909X.2003.02.001
[39]	章志, 刘宪光, 周凯, 等. 海岸侵蚀脆弱性及驱动因子分析: 以江苏中部海岸为例[J]. 海洋学研究, 2023, 41(4): 70-83. doi: 10.3969/j.issn.1001-909X.2023.04.007 ZHANG Z, LIU X G, ZHOU K, et al. Vulnerability and driving factors of coastal erosion: A case study of the central coast of Jiangsu[J]. Journal of Marine Sciences, 2023, 41(4): 70-83. (in Chinese with English abstract doi: 10.3969/j.issn.1001-909X.2023.04.007
[40]	DODET G, BERTIN X, BRUNEAU N, et al. Wave-current interactions in a wave-dominated tidal inlet[J]. Journal of Geophysical Research: Oceans, 2013, 118(3): 1587-1605.
[41]	李明杰, 吴少华, 刘秋兴, 等. 风暴潮、大潮对广西涠洲岛西南沙滩侵蚀的影响分析[J]. 海洋学报, 2015, 37(9): 126-137. doi: 10.3969/j.issn.0253-4193.2015.09.013 LI M J, WU S H, LIU Q X, et al. Impacts of storm surge and spring tide on the beach erosion of the southwestern Weizhou Island, Guangxi Province[J]. Haiyang Xuebao, 2015, 37(9): 126-137. (in Chinese with English abstract doi: 10.3969/j.issn.0253-4193.2015.09.013
