黄陵背斜东北翼岩溶水系统特征及其对引调水隧洞工程的影响

颜慧明; 常威; 季怀松; 邓争荣; 郭绪磊; 陈林; 黄琨

doi:10.19509/j.cnki.dzkq.2022.0165

黄陵背斜东北翼岩溶水系统特征及其对引调水隧洞工程的影响

doi: 10.19509/j.cnki.dzkq.2022.0165

颜慧明^1,,
常威¹,
季怀松²,
邓争荣¹,
郭绪磊²,
陈林²,
黄琨^2, ,

1.
长江岩土工程有限公司，武汉 430010
2.
中国地质大学(武汉)环境学院，武汉 430078

基金项目:

国家自然科学基金项目 42172281

长江岩土工程有限公司项目 CJ2022Z06

详细信息

作者简介:
颜慧明(1975—)，男，高级工程师，主要从事工程地质与水文地质研究工作。E-mail: yyyhm@263.net

通讯作者:
黄琨(1984—)，男，副教授，博士生导师，主要从事岩溶水文地质方面的研究工作。E-mail：cugdr_huang@cug.edu.cn

中图分类号: P641.134
计量
- 文章访问数: 871
- PDF下载量: 63
- 被引次数: 0
出版历程
- 收稿日期: 2022-01-12
- 网络出版日期: 2022-11-10

Characteristics of the karst water system on the northeast wing of the Huangling anticline and its impact on water diversion tunnel engineering

1.
Changjiang Geotechnical Engineering Co.Ltd., Wuhan 430010, China
2.
School of Environmental Studies, China University of Geosciences(Wuhan), Wuhan 430078, China

摘要

摘要:
陵背斜东北翼地层以碳酸盐岩和碎屑岩相间的组合形式出现，碳酸盐岩分布区岩溶发育强烈，岩溶突涌水是该区地下工程建设的重要影响因素。以某重大引调水工程黄陵背斜段为研究对象，综合采用岩溶水文地质调查、示踪试验、水文地球化学等多种方法对研究区岩溶水系统特征及隧洞突涌水条件进行了识别和分析。结果表明：区内存在4个子含水系统，垂向上构成了透水性强-弱相间的结构，发育了浅部快速循环、中间快速循环和深部慢速循环的多级水流系统，断裂构成各子含水系统间发生水力交换的垂向通道。工程输水隧洞主体在深部灯影组(Z₂dn)和天河板组-石龙洞组(∈₁t+sl)子含水系统中穿越，岩溶发育总体较弱，但在穿越店垭断裂时存在导通上部娄山关组-南津关组(∈₃l-O₁n)强岩溶子含水系统而发生较大规模高压突涌水的可能。施工支洞穿越∈₃l-O₁n子含水系统中白龙洞水流系统的排泄区，遭遇管道式突涌水事故的风险高。多种水文地质方法的联合解译可提高识别岩溶水系统特征和突涌水条件的精度。
- 黄陵背斜 /
- 岩溶水系统 /
- 示踪试验 /
- 水化学 /
- 输水隧洞
Abstract:
The strata in the northeast wing of the Huangling anticline consist of interbedded carbonate rocks and clastic rocks. As the carbonate rocks underwent strong karstification, karst water inrush would be a significant factor impacting the construction of underground engineering in this area. Taking the Huangling anticline section of a critical national water diversion project as the research object, the characteristics of the karst groundwater system and the water inrush conditions in tunnels were identified by various methods, such as karst hydrogeological surveys, tracer tests and hydrogeochemistry analysis. These results show that the aquifer system contains four sub-aqueous systems with a structure of strong and weak permeable interlayers in the vertical direction, in which a multi-stage karst groundwater system has developed with shallow rapid circulation, intermediate rapid circulation and a deep slow circulation subflow systems. The faults constitute the vertical channels for hydraulic exchange between sub-aquifer systems. The water diversion tunnel primarily crosses the deep Dengying Formation (Z₂dn) and Tianheban-Shilongdong Formation(∈₁t+sl) aquifer systems with weak karst development. However, a large-scale high-pressure water inrush accident may occur when passing through the Dianya fault, which may transfer groundwater from the upper karst sub-aquifer system of the Loushanguan Formation-Nanjinguan Formation (∈₃l-O₁n) into the tunnel. The risk of encountering conduit water inrush accidents is high during construction when the construction branch tunnel passes through the discharge area of the Bailongdong groundwater flow system in the ∈₃l-O₁nsub-aquifer systems. The accuracy of identifying of karst groundwater flow system features and inrush conditions can be improved by joint interpretation of multiple hydrogeological methods.
- Huangling anticline /
- karst groundwater system /
- tracer test /
- hydrochemistry /
- water diversion tunnel

HTML全文

图 1 研究区综合水文地质平面图

Figure 1. Comprehensive hydrogeological map of the study area

下载: 全尺寸图片幻灯片

图 2 输水隧洞(A-A′)水文地质剖面图

Z₂d.陡山沱组; Z₂dn.灯影组; ∈₁t+sl.天河板组-石龙洞组; ∈₁s+sp.水井沱组-石牌组; ∈₂q.覃家庙组; ∈₃l.娄山关组; O₁n.南津关组; O₁f+h+d.分乡组-大湾组; O₂₊₃.中上奥陶统

Figure 2. Hydrogeological profile of the water diversion tunnel (A-A′)

下载: 全尺寸图片幻灯片

图 3 B-B′水文地质剖面图

Figure 3. B-B′ hydrogeological profile

下载: 全尺寸图片幻灯片

图 4 地下水示踪试验的示踪剂浓度历时曲线

Figure 4. Breakthrough curves of groundwater tracer tests

下载: 全尺寸图片幻灯片

图 5 研究区典型水点的水化学Piper三线图

Figure 5. Piper trilinear chart of typical water points in the study area

下载: 全尺寸图片幻灯片

图 6 研究区典型水点Mg²⁺/ Ca²⁺与ρ(HCO₃^-)关系图(a)和氘氧同位素分布图(b)

Figure 6. Relationships between Mg²⁺/Ca²⁺ and HCO₃^- concentration (a), distribution of deuterium and oxygen isotopes of typical water point in the study area

下载: 全尺寸图片幻灯片

表 1 水文地质钻孔基本信息

Table 1. Basic information on hydrogeological boreholes

钻井号	孔口高程/m	承压高度/m	取样深度/m	取样高程/m	地下水取样层位
ZK01	902	—	326	576	∈₃l
ZK02	652	—	69	583	∈₁t+sl
ZK03	593	700	0	593	∈₁t+sl
注：取样深度为孔口到孔内取水点的距离；∈₃l.娄山关组；∈₁t+sl.天河板组；∈₁t+sl.石龙洞组

下载: 导出CSV

表 2 示踪试验结果及计算参数

Table 2. Tracer test results and calculated parameters

基本参数	天星村→白龙洞	云起山→白龙洞	神农村→老龙洞	郑家坡→老龙洞
投放时间	2020/6/20	2020/6/20	2021/7/24	2021/8/9
示踪剂	荧光素钠	罗丹明	荧光素钠	罗丹明
投放量/kg	4.00	3.50	3.00	6.00
平面距离/m	5 700	5 300	2 700	4 300
初次检测时间/h	23.16	131.25	197.75	83.75
最大流速/(m·h^-1)	246.11	40.38	13.65	51.34
峰值运移时间/h	35.66	183.46	375.00	100.25
平均流速/(m·h^-1)	159.84	28.89	7.20	42.89
注：最大流速=平面距离/初次检测时间；平均流速=平面距离/峰值运移时间

下载: 导出CSV

表 3 典型地下水点的化学组分及补给高程估算

Table 3. Hydrochemistry components and estimated recharge elevations of typical groundwater points

采样点	K⁺	Na⁺	Ca²⁺	Mg²⁺	Sr²⁺	Cl^-	SO₄^2-	HCO₃^-	TDS	取样高程/m	δ¹⁸O/‰	δD/‰	补给高程/m
采样点	ρ_B/(mg·L^-1)									取样高程/m	δ¹⁸O/‰	δD/‰	补给高程/m
SP1	0.56	2.69	142.22	4.64	0.22	5.88	20.85	347.80	350.75	807	-7.60	-49.87	—
SP2	2.42	5.08	128.54	6.44	0.29	6.54	43.56	280.68	332.93	577	-7.11	-48.02	—
SP3	2.99	5.05	141.04	6.32	0.17	7.09	43.59	274.58	343.38	637	-7.56	-49.51	—
SP4	0.80	3.16	127.18	0.80	0.16	3.79	0.00	298.98	287.67	848	-7.77	-51.30	—
SP5	1.39	1.78	94.15	3.84	0.19	3.41	15.70	237.97	239.25	542	-8.03	-51.85	—
余家岭	0.00	3.22	78.41	4.07	0.13	9.75	19.27	227.15	228.29	736	-7.58	-49.05	—
郑家坡	4.40	2.22	86.62	5.43	0.12	2.94	15.29	323.39	278.59	908	-8.06	-52.92	—
青龙洞	4.22	6.38	103.28	5.96	0.18	20.41	28.08	298.09	317.38	450	-7.34	-48.77	543
百家洞	2.29	4.94	57.92	4.55	0.11	6.34	17.40	183.05	184.97	507	-7.78	-50.37	723
白龙洞	2.44	2.66	60.14	16.80	0.12	4.93	19.11	271.53	241.84	400	-8.21	-52.95	902
老龙洞	2.81	3.19	58.67	14.64	0.29	5.61	29.80	280.68	255.05	466	-8.48	-54.95	1 015
ZK01	4.35	13.33	58.19	12.37	0.29	10.32	34.95	231.86	249.43	576^*	-8.15	-54.04	877
ZK02	2.04	3.09	59.33	25.62	0.45	1.24	81.98	256.27	301.44	583^*	-9.73	-66.57	1 536
ZK03	1.87	2.94	56.86	26.46	0.47	1.04	89.19	247.12	301.93	593	-9.76	-67.18	1 552
注：*为孔内地下水取样点高程；TDS.总溶解性固体物质

下载: 导出CSV
